Fantic continues to grow in enduro and now presents the XEF 250

Fantic is expanding its Enduro range for the 2021 model year to include the XE 125 with the new four-stroke XEF 250 with a Yamaha engine.

The Fantic XEF 250 Enduro carries the 249 cm³ single cylinder with electric starter made by the Japanese, which has been brought up to Euro 5 level in cooperation with Yamaha. It is shifted by a six-speed gearbox. There are no performance data. The motor control was developed by Athena-GET and can be networked via app. In this way, various votes can be influenced via the smartphone. Arrow supplies a specially tuned exhaust.

The chassis is based on the Yamaha frame, an aluminum alloy perimeter combined with suspension Kayaba. The fork is an inverted SSS (Speed ​​Sensitive System) unit with 48mm stanchions, 310mm travel and specific enduro tuning.
The rear mono, with progressive articulation, offers 317 mm of wheel travel and is fully adjustable.

The aluminum swingarm and the rims close the picture DID from 21 and 18 inches (Metzeler Six Days Extreme tires) and the braking system Nissin with single discs of 270 and 245 mm.

The superstructures have been designed to allow ergonomics in the saddle and freedom of movement.

The lights are LED, the tank holds 7.9 liters, sump guard and handguards are standard and the saddle has a high grip coating.
Weight is stated in 115 kg.

The technical sheet

TECHNICAL SPECIFICATIONS FANTIC XEF 250
ENGINE:
Type: Single-cylinder 4-strokes, liquid cooled, 4 valves, DOHC
Displacement: 249 cc
Induction: Fuel Injection
Bore: 77.0 mm
Stroke: 53.6 mm
Compression ratio: 13.8: 1
Ignition system: TCI
Starting system: Electric starter
Lubrication system: Wet sump
Trasmission: 6-speed
Clutch: Wet, multiple-disc
CHASSIS:
Frame type: Aluminum perimeter frame
Caster angle: 27.2°
Trail: 116 mm
Rear frame: Aluminum
Swingarm: Aluminum with variable section and progressive link
Rims: 21×1.60 – 18×2.15
Tyres: 90/90×21 – 130/90×18
Brakes: Hydraulic disc ø270mm – Hydraulic disc ø245mm
Front suspension: KYB ø48 mm, fully adjustable, wheel travel 310 mm
Rear suspension: KYB, fully adjustable, wheel travel 317 mm
OVERALL DIMENSIONS:
Length: 2175 mm
Width: 825 mm
Height: 1270 mm
Seat height: 955 mm
Wheelbase: 1480 mm
Curb weight: 115 kg
Fuel tank capacity: 7.9 l
Engine oil quantity: 0.95 l
